Newmar Bay Star 3423 Motor Home Class A For Sale

•

  Newmar Bay Star Class A gas motorhome 3423 highlights:

  • Rear Private Bedroom
  • Shower Skylight
  • Booth Dinette
  • Swivel Seats
  • Full Bathroom



  Start taking your best vacations in this motorhome! The large slide provides added space, along with the king bed slide out in the rear private bedroom. You can easily prepare meals on the recessed three burner cooktop, or use the stainless steel convection microwave, and the pantry will be perfect for dry goods or snacks. This model includes a 74" sofa comfort lounge and a booth dinette (sleeper) slide for seating and sleeping space, plus there is a Samsung LED TV in the living room and bedroom so you can watch your favorite shows. You'll find storage space up front, plenty of overhead compartments, plus lit basement storage.



  Each Bay Star Class A gas motorhome by Newmar delivers a smooth ride thanks to the standard electronic stability control, along with the 7.3-liter V8 engine with 350 HP and 468 lb./ft. of torque. The exterior is sure to turn heads with its full-paint Masterpiece Finish, and you'll have three interior decor choices and three wood choices to truly make the coach your own. Each model includes newly styled Williamsburg furniture, luxurious vinyl plank flooring, polished solid surface countertops in the kitchen, plus many more comforts. Head outside to find lit basement storage, a 5.5kW Onan generator with remote switch, and smart level hydraulic leveling jacks with a Bluetooth compatible touch pad for set up easy as 1-2-3! You can further customize your coach with the many options that are offered!

  View All 3423 In Stock »

  We have 1 3423 available

  View Inventory

  Specifications

  Sleeps	5
  Slides	3
  Length	34 ft 11 in
  Ext Width	8 ft 6 in
  Ext Height	12 ft 10 in
  Int Height	7 ft
  Interior Color	Arlow, Stowe, Vista
  Exterior Color	Cardinal, Granite, Harvest
  Hitch Weight	5000 lbs
  GVWR	26000 lbs
  Dry Weight	21800 lbs
  Cargo Capacity	4200 lbs
  Fresh Water Capacity	75 gals
  Grey Water Capacity	60 gals
  Black Water Capacity	40 gals
  Furnace BTU	35000 btu
  Generator	5.5 kW Onan
  Fuel Type	Gas
  Engine	7.3L V8
  Chassis	Ford F-53
  Horsepower	350 hp
  Fuel Capacity	80 gals
  Wheelbase	234 in
  Available Beds	King
  Torque	468 ft-lb
  Refrigerator Type	Norcold
  Refrigerator Size	10 cu ft
  Convection Cooking	Yes
  Cooktop Burners	3
  Shower Size	40" x 30"
  Number of Awnings	1
  Axle Weight Front	9000 lbs
  Axle Weight Rear	17500 lbs
  LP Tank Capacity	25 gals
  Water Heater Capacity	6 gal
  Water Heater Type	Gas/Electric
  AC BTU	27000 btu
  TV Info	LR Samsung LED, BR Samsung LED
  Awning Info	Carefree Travel'r Power Side Awning w/Strip Lighting
  Gross Combined Weight	30000 lbs
  Shower Type	Standard
  Electrical Service	50 amp
